ePAQ-9410/20 Substation Gateway

Harness the Potential of Your Substation Devices

The ePAQ-9410/9420 Multifunction Gateways should be at the core of your substation management program for the Smart Grid. Whether serving as an expandable front end for legacy RTUs or as the platform for the next stage of your distribution automation program, the ePAQ-9410/9420 can serve to connect the myriad intelligent devices within your substation to your larger enterprise in a reliable and secure fashion.

Data Concentration for Your Substation Devices

The ePAQ-9410/9420 can integrate the complete catalog of IEDs using our library of legacy or open, industry standard protocols, be they serial or LAN based. In addition to data concentration, the unit can perform custom computations needed for filtering, translating, pre-processing or reduction. With ConfigWiz®, raw or processed IED data can be distributed to any remote enterprise via SCADA, maintenance or engineering activities through serial or WAN based channels. If needed, such transfers can be encrypted and authenticated for greater security.

  • Interface with all devices using any open Protocol and over any media
  • Choice of RJ-45 or DB-9 Serial Port Connections
  • Redundant architecture for critical applications
  • Easy, Modular Expansion for additional Hardware I/O Points
  • Serial ports may be configured for Rear Panel DB-9 Connectors (option)
  • Security Tools available for meeting latest NERC CIP and Cyber Security Requirements
  • Quick and easy configuration with provided ConfigWiz® Windows Software
  • SD Memory Card and USB Ports for easy, but secure, User Expansion and Update
  • Embedded Web Server and HMI for Local or Remote Display
  • HMI & Web Browser Support
