eXP-9430 Communication Port Expander

Expand Your Substation Data Concentrator and Provide Secure Access for your Entire Enterprise

The eXP-9430 is a compact addition to your ePAQ-9410/9420/9425 Multifunction Gateway which expands the number of serial or IP ports for access to additional devices or IEDs.

Housed in a 19” width enclosure with a 1U footprint, the eXP-9430 has all front access connections for convenient rack or panel mounting.This allows for easy expansion into available station house space.

Convertible Communications Ports for Flexible Installations

The eXP-9430 provides 16 additional ports which are convertible RS-232 or RS-485 allocated on a per port basis. Optionally, these may be provided as eight Serial FiberPorts with eight ST (multimode) or SC (single mode) connections.

The 10/100 BaseTX connection is through a standard RJ-45 connection, with the 100 BaseFX interface using standard ST fiber connectors.

  •  Expand your QEI Substation platforms with additional Devices, Protocols and Communication Interfaces with a Convenient Modular Package
  • Ethernet 10/100 BaseTX and 100 BaseFX ports for IP accessibility
  • Sixteen RS-232/RS-485 or eight Serial Fiber ports for incorporating Future, Current or Legacy Devices
  • Works within Your Substation plan to meet NERC-CIP and Cyber Security requirements
  • Quick and easy configuration with provided ConfigWiz® Windows Software
  • Front Panel LED Indicators for easy assessment of operation
  • IRIG-B Interface for System Time Synchronization
  • Front access connections for Rack or Panel Mounting to simplify installation
